Model:JD300-3-45F
Dia.300mm(12inch) R Y G Full Ball With Turn Right Green Arrow And Red Green 2 Digits Countdown LED Traffic Light With Clear Lens.
can provide customers with personalized, di
Dia.300mm(12inch) R Y G Full Ball With Turn Right Green Arrow And Red Green 2 Digits Countdown LED Traffic Light With Clear Lens compared with similar products on the market, it has incomparable outstanding advantages in terms of performance, quality, appearance, etc., and enjoys a good reputation in the market.BBM Traffic Light summarizes the defects of past products, and continuously improves them. The specifications of Dia.300mm(12inch) R Y G Full Ball With Turn Right Green Arrow And Red Green 2 Digits Countdown LED Traffic Light With Clear Lens can be customized according to your needs.
versified and systematic services.
Size:300mm
Color:Red/Yellow/Green
MOQ:1Set
Place of Origin:Shenzhen,China
Packing:K=K Carton
Delivery time:7~10 days
Keywords: Red Yellow Green Ball Signal Light , Traffic Signal Light With Countdown, Signal Light, Road Traffic light With Arrow, 300mm led traffic light etc.
Application: Red Yellow Green Traffic Light is widely used in Vehicle Road, Railway, Cross Road, to indicate whether vehicles can go or not.
Strengths: Good Visibility, Energy Saving, Low Thermal Energy, Long Life Span, Impact Resistance, Good Quality, Competitive Price.
Color | LED Q.ty | Light Intensity | Wave Length | Power Fact | Viewing Angle | Power | Working Voltage | Housing Material |
Green Arrow | 69pcs | ≤655cd | 505±5nm | >0.9 | 30° | ≤5.5W | 85V-265VAC or 9-36 VDC | PC,UV Resistant |
Red Ball | 168pcs | ≤840cd | 625±5nm | ≤8W | ||||
Yellow Ball | 168pcs | ≤840cd | 590±5nm | ≤8W | ||||
Green Ball | 168pcs | ≤1596cd | 505±5nm | ≤14W | ||||
Red Countdown | 64pcs | ≤320cd | 625±5nm | ≤3W | ||||
Green Countdown | 64pcs | ≤608cd | 505±5nm | ≤5W |
Part name | Light | Bracket | Sun Visor | M4x10 Screw | M4x20 Screw | Wiring Box And Gasket | Using Manual | Certificate |
Q'ty.(pcs) | 1 | 2 | 4 | 16 | 4 | 1 | 0 | 0 |
1. LED:Our LED lamp beads are UL Listed, each LED is imported from Taiwan. The LED life span up to 100000 hours. Red LED with 4000-5000mcd brightness, Green LED with 7000-9500mcd brightness. LED light-emitting diode is a light source, with stable performance and ideal display effect.
2. COLD ROLLED PLATE HOUSING& MODULES:2.The surface is sprayed with conformal coating, with the waterproof, dustproof, mildew proof function. The modules diameter about 100 mm(4 inch). Its surface injection of pollution-free glue, have waterproof and dust resistance.
3. VISORS :3.Integrated with the housing, easy to install and maintain traffic lights. With the visor, it can effectively block the direct sunlight and prolong the service life, making the display better.
4. WORKING VOLTAGE & EASY INSTALLATION:Operating voltage of DC9-36V or 85V-265VAC; Red light to R terminal, Yellow light to Y terminal, Green light to G terminal, common is public line.
5. WARRANTY: Two years warranty promise.
